large torque CYS-BLS5815 CYS Factory 1/10 RC Aluminum Boat with High Safety Brushless Digital Servo 15KG Torque Battery-Metal
large torque CYS-BLS5815 CYS Factory 1/10 RC Aluminum Boat with High Safety Brushless Digital Servo 15KG Torque Battery-Metal
Regular price
$135.00 USD
Regular price
Sale price
$135.00 USD
|
Item NO.
|
CYS-BLS5815
|
|
Type
|
Digital
|
|
Gear Type
|
Titanize
|
|
Weight
|
77g
|
|
Size
|
40*20*39mm
|
|
Control System
|
(+)Pulse Width Control 1500μsec Neutral
|
|
Operating Voltage
|
6.0V-7.4V
|
|
Operating Temperature Range
|
(-)10 to +50 degree C
|
|
Operating Speed @ 6.0V-7.4V
|
0.08sec - 0.07sec at no load
|
|
Stall Torque @ 6.0V -7.4V
|
13kg.cm-15kg.cm
|
|
Current Drain (6.0V)
|
20mA/idle and 80mA no load operating
|
|
Current Drain (7.4V)
|
20mA/idle and 100mA no load operating
|
|
Stall Current
|
3.0A/3.5A
|
|
Dead Band Width
|
2μsec
|
|
Bearing Type
|
Dual Ball Bearing
|
|
Motor Type
|
Brushless
|
|
Horn gear spline
|
25T
|
|
Cable/Plug
|
300mm/JR
|
|
Wire information
|
Brown(N) Red (P) Orange(S)
|
