Micro Servo CYS-S0006 Mini 6g Analog RC Servo Battery-Powered Coreless Motor High Torque 9g Plastic Gear Micro Radio Systems RC Parts Accs
- Sale price
- $11.45
- Regular price
-
- Regular price
- $11.45
- Unit price
- per
-0%
Vendor: roboticu
Only
999
items in stock!
Out of stock!
Guaranteed safe checkout
Couldn't load pickup availability
Description
Description
6g Mini &Micro Analog RC Servo with Plastic Gear Coreless Motor for Rc Helicopter
Product Paramenters
|
Item NO.
|
CYS-S0006
|
|
Type
|
Mini Analog Servo
|
|
Gear Type
|
Plastic Gear
|
|
Weight
|
6g
|
|
Size
|
21.5*11.8*22.7mm
|
|
Control System
|
(+)Pulse Width Control 1500μsec Neutral
|
|
Operating Voltage
|
6.0V-7.4V
|
|
Operating Temperature Range
|
(-)10 to +50 degree C
|
|
Operating Speed @ 4.8.0V-6V
|
0.13sec - 0.11sec at no load
|
|
Stall Torque @ 4.8V -6V
|
1.0g.cm-1.2kg.cm
|
|
Current Drain (4.8V)
|
10mA/idle and100mA no load operating
|
|
Current Drain (6.0V)
|
10mA/idle and 120mA no load operating
|
|
Stall Current
|
390mA/460mA
|
|
Dead Band Width
|
5μsec
|
|
Motor Type
|
Coreless Motor
|
|
Horn gear spline
|
20T
|
|
Cable/Plug
|
180mm/JR
|
|
Wire information
|
Brown(N) Red (P) Orange(S)
|
